MY-B005F
The three-category fully automatic blood analyzer is a device used to analyze human blood samples. It can automatically perform measurements and analysis of three basic blood parameters: white blood cell count, red blood cell count, and hemoglobin level. This instrument is typically utilized in medical laboratories, hospitals, clinics, and research institutions for assessing the blood condition of patients.
Product Advantage：
Fully automated operation
Rapid analysis
Accurate measurement
Measurement of multiple parameters
Sample processing capability
Data management functionality
Product Uses：
Medical laboratories, hospitals, clinics, and research institutions for assessing the blood condition of patients.
Product Operate Guide：
The operation of the machine is not done once and for all, and it is necessary to pay special attention to the state of the machine during each packaging process. In order to effectively manage and maintain the packaging machine and control the product quality, in addition to regular maintenance, the auxiliary personnel and feeding personnel of the equipment also need to follow the following operating procedures.
Auxiliary personnel
Turn on the power switch
Check whether the air pressure is sufficient (must reach 0.6Mpa)
Click the host to start, and check whether each action is working properly
Check and clean up each box room
Put the bag, load the material, put the material box
Click the host to start
The product that is packaged in vacuum for the first time should be checked whether the seal is firm, whether the suction is tight and through the water check(Must check vacuum chamber 1-10)
During the production process, check the product sealing and pumping conditions continuously
Every 2 hours after the machine runs, must be the top cover of the machine, bag clip, and funnel mouth, carried out with an air gun clean
The bag or material dropped on the machine, should be hooked out with a hook, do not take it by hand
Detection of Reticulocyte
Quantitative detection of RET for capillary blood and
predilution blood.
Up to 7 report parameters.
Provide clinical reference information of RET maturity,
anemia treatment monitoring, and differential diagnosis.
Optical Platelet Detection
RET Detection with PLT-O parameter.
PLT-O ensures results more accurate through staining,
to avoid interferences.
Detection Technology:Fluorescence Staining & Flow Cytometry
Detection mode:
CBC
CBC+DIFF
CBC+RET
CBC+DIFF+RET
Sample mode:Whole Blood Mode, Low Value Leukocyte Mode, Predilution Mode, and Sample Research Mode
Sample volume:
Whole blood mode: 88ul
Predilution mode: 70ul
Throughput:
CBC+DIFF: 100T/H
CBC+RET: 83T/H
CBC+DIFF+RET: 83T/H
Reporting parameters (36 in total):
Leukocyte: WBC、NEUT(#,%)、LYMPH(#,%)、MONO(#,%)、EO(#,%)、BASO(#,%)、IG(#,%)
Erythrocyte: RBC、HGB、HCT、MCV、MCH、MCHC、RDW-SD、RDW-CV、NRBC(#,%)
Platelets: PLT、PDW、MPV、P-LCR、P-LCC、PCT
Reticulocyte: RET(#,%)、 IRF、 LFR、 MFR、 HFR、 RET-He
Linear range:
WBC: 0~500x109/L
RBC: 0 - 8.60×1012/L
HGB: 0 - 260g/L
PLT: 0~5000x109/L
Features:
5-part differentiation, 27 parameters, 3 DIFF scatter grams and 1 BASO scatter gram, 3 histograms for WBC, RBC and PLT.
Tri-angle semi-conductor Laser scatter combined with chemical dye method, advanced flow cytometry
Compact, powerful and affordable
Only 15ul sampling volume
Up to 60 samples per hour
3 counting modes: venous blood, capillary blood and pre-diluted
Capability to flag abnormal samples
Large storage capacity: up to 50,000 samples
Technical Specifications:
Principles
Impedance method for WBC, RBC, PLT counting
Cyanide-free reagent for Hemoglobin test
Flow Cytometry (FCM), Semi-conductor Laser scatter, chemical dye method, independent Basophil channel
Parameters
WBC, Lym%, Lym#,Mon%, Mon#,Neu%, Neu#,Eos%, Eos#, Bas%, Bas#, RBC, HGB, HCT, MCV, MCH, MCHC, RDW-CV, RDW-SD, PLT, PDW, MPV, PCT, and 4 research parameters LIC%, LIC#, ALY%, ALY#
3 DIFF scatter grams and 1 BASO scatter gram, 3 histograms
Throughput
Up to 60 samples per hour
Sample Volume
Whole Blood: 15ul, Pre-diluted: 20ul
Test Mode
CBC CBC+DIFF
Performance
Carryover Repeatability Linearity
WBC ≤0.5% ≤2.0% (4-15×109/L) 0.00-300×109/L
RBC ≤0.5% ≤1.5% (3.5-6.0×1012/L) 0.00-8.5×1012/L
HGB ≤0.5% ≤1.5% (110-180g/L) 0-250g/L
PLT ≤1.0% ≤4.0% (150-500×109/L) 0.00-3000×109/L
Data Storage Capacity
Up to 50,000 results including numeric and graphical information
Communication
LAN port supports HL7 protocol
Operating Environment
Temperature: 15oC-30oC
Humidity: 30-85%
Air Pressure: 70-106 kPa
Power Requirement
A.C. 100-240V, ≤300VA, 50/60Hz
Dimension and Weight
360mm(L) × 470mm(W) × 430mm(H)
Weight: 28kg
Parameters：
5-part WBC Differential
25 Reportable Parameters
2 Histograms
2 Scatter Grams
Abnormal Sample Alarm
Sample Mode：Whole Blood (Venous/Capillary), Pre-dilution
QC Methods：L-J QC, X-B QC
Power Supply：100-240 V~ 50/60 Hz
Weight：21 kg
Dimension：328 mm x 471 mm x 446 mm(LxWx H)
Data Storage：10000
Screen Type：10.4 inch Resistive Screen
Operating Conditions：18~30"C, <80% Relative Humidity, 75 kPa~106 kPa
Function: Automated WBC 3-differential, 22 parameters with 3 color histograms (WBC, RBC, PLT)
Principal: Electronic impedance, SFT method for hemoglobin
Throughput: ≥60T/H
Analysis Mode: Optional venous blood, anticoagulant blood and prediluted blood
Sample Volume: Anticoagulant whole blood ≤9.6µL, Anticoagulant capillary blood ≤9.6µL, prediluted capillary blood ≤20µL, the sample volume for repeating two times testing and avoiding second sampling
Working Mode: Automatic sampling, detecting automatic testing, furnished with dilutor, no need diluting outside. Automatic dispensing lyse and making second diluting automatically
Block-clearing: Soak and washing back and forth, high pressure burning. Boast the function of monitoring incomplete blockage
Alarm: Automated system diagnosis, self testing, fault alarm and reagent shortage alarm
Automated Maintenance: Automated washing during power on and power off, reducing the blockage rate
Standby Protection: 24 hours switch on, automatic sleep and wake up function
Storage: Large quantity test results storage, at least 400 thousand test results with comprehensive information. Extended SD memory supported.
Control Mode: Quality control mode of L-J, X-B and X-r. Westguard quality control regulation
Calibration Mode: Manual and automatic calibration available. Fresh blood calibration available also.
Reference Value Setting: Many reference value ranges (children, adult and the aged). The appropriate reference value range could be automatically selected according to the inputted age and sex.
Discriminator Function: Float and fix discriminator. Manual adjust available
Display: TFT LCD (Optional Touch Screen)
Input Mode: Standard mouse and keyboard. Optional bar code reader
Print Mode: Internal high-speed thermal printer. Optional connection with specified external printer. English printouts
Report Format: Many kinds of report format (not less than 8 kinds)
Reagents System: Open reagent system. No cyanogen reagents
●3-part differentiation of WBC, 23 parameters, single channel counter
●Volume measurement by time ,not wrong warning
●Adanced valve technology,long life
● RS232 interface, PC connecting
up to35/ 60 samples test per hour
● Electrical resistance for counting and SFT method of hemoglobin
● Low sample consumption : venous 9.8 ul, capillary 9.6 ul, pre-diluted 20 ul for twice testing one time
● 8.4” color TFT, Windows interface all testing parameter displayed simultaneously
● Windows operation system graphical buttons mouse and keyboard operation
● Double convolution and intelligent fitting
● Automatic diluting , Mixing , rinsing and clog clearing
● Automatically sample probe cleanning (inside and outside)
● Large storage capacity: up to 10,000 samples +3 histograms
● Internal thermal-sensitive printer or external printer.
● RS232 interface, PC connecting
Main Technical Specifications
Methodology: Electrical resistance for counting, hemoglobin cyanide method and SFT method for hemoglobin
Parameter: 3-part differentiation of WBC; 20 parameters and 3 color histograms (WBC, RBC, PLT)
Work mode : double Channel + unique Hemoglobin test system
Sample volume: 9.8μL for Venous and capillary mode, 20μL for pre-diluted mode
Throughput: More than35 or 60 samples per hour, operate 24 hours per day, auto sleeping and waking-up functions
Storage: up to 100000 sample results including histograms can be stored, convenient for inquiry and management of history data
Operation langue: English
QC control : X-B, L-J, X , SD, CV %
Reference Value Setting : Male , Female, Children, Neonate
Input / output : RS232, parallel printer and keyboard
Print : Graphic thermal printer with various printing format, optional external printer
Power supply : 220 V ±22 VAC, 50±1Hz
Parameters : WBC, Lymph#, Mid#, Gran#, Lymph%, Mid%, Gran%, RBC, HGB,HCT, MCV, MCH, MCHC, RDW-CV, RDW-SD, PLT, MPV,PDW,PCT,L-PCR
3 –histograms : WBC,RBC and PLT
Specification sheet
●3-part differentiation of WBC, 24 parameters, double channel counter
●8.4 inches color touch screen, Windows interface all testing parameter displayed simultaneously
●Waste full alarm automatically
●external printer such as Epson LQ-630k, Epson LQ-350, Epson M200/M201, HP P1007,HP 1020Plus
●up to 60 samples test per hour
● Electrical resistance for counting and SFT method of hemoglobin
● Low sample consumption : venous 9.8 uL, pre-diluted 20 uL for twice testing one time
● Windows operation system graphical buttons mouse and keyboard operation
● Double convolution and intelligent fitting
● Automatic diluting , Mixing , rinsing and clog clearing
● Automatically sample probe cleaning (inside and outside)
● Large storage capacity: up to 100,000 samples +3 histograms
● Internal thermal-sensitive printer.
● RS232 interface, PC connecting
Main Technical Specifications
Methodology: Electrical resistance for counting, hemoglobin cyanide method and SFT method for hemoglobin
Parameter: 3-part differentiation of WBC; 21 parameters and 3 color histograms (WBC, RBC, PLT) Work mode : double Channel + unique Hemoglobin test system Sample volume: 9.8μL for Venous mode, 20μL for pre-diluted mode Throughput: More than 60 samples per hour, operate 24 hours per day, auto sleeping and waking-up functions Storage: up to 100000 sample results including histograms can be stored, convenient for inquiry and management of history data Operation langue: English QC control : X-B, L-J, X , SD, CV % Reference Value Setting : Male , Female, Children, Neonate Input / output : RS232, parallel printer and keyboard Print : Graphic thermal printer with various printing format, optional external printer Temperature : 18℃ - 30℃,wet ≤ 10-90% Power supply : 220 V ±22 VAC, 50±1Hz Dimension : 33 CM ( L ) * 38 CM ( W ) * 43 CM ( H ) Weight : 20 KG Precision Parameters linear rang
